R87T-A6A05H
AC Fans
- Manufacturer No:
- R87T-A6A05H
- Manufacture:
- Omron Electronics Inc-EMC Div
- Datasheet:
- R87T-A6A05H
- Description:
- FAN AXIAL 151X38MM 230VAC WIRE
In Stock
0 pcs On sales
$139.86
Product Parameter
- Noise
- 58.0 dB
- Voltage Range
- 195.5 ~ 253VAC
- Width
- 38.00mm
- Static Pressure
- 0.430 in H2O (107.1 Pa)
- Series
- R87T
- Voltage - Rated
- 230VAC
- Weight
- 1.9 lbs (861.8 g)
- Lifetime @ Temp.
- -
- Air Flow
- 203.4 CFM (5.70m³/min)
- Material - Blade
- Zinc
- Fan Type
- Tubeaxial
- Material - Frame
- Aluminum
- Features
- -
- Size / Dimension
- Round - 151mm Dia
- Approvals
- CSA, UL
- Ingress Protection
- -
- Part Status
- Active
- Current Rating (Amps)
- 0.190A
- Termination
- 2 Wire Leads
- Operating Temperature
- -4 ~ 158°F (-20 ~ 70°C)
- Bearing Type
- Ball
- RPM
- 3100 RPM
- Power (Watts)
- 48.00W
