G6HK-2-DC6
Signal Relays, Up to 2 Amps
- Manufacturer No:
- G6HK-2-DC6
- Manufacture:
- Omron Electronics Inc-EMC Div
- Datasheet:
- G6HK-2-DC6
- Description:
- RELAY TELECOM DPDT 1A 6VDC
In Stock
0 pcs On sales
$0
Product Parameter
- Series
- G6H
- Mounting Type
- Through Hole
- Features
- -
- Coil Insulation
- -
- Coil Type
- Latching, Dual Coil
- Coil Resistance
- 180 Ohms
- Packaging
- Tube
- Contact Material
- Silver (Ag), Gold (Au)
- Relay Type
- Telecom
- Switching Voltage
- 125VAC, 110VDC - Max
- Part Status
- Obsolete
- Termination Style
- PC Pin
- Seal Rating
- -
- Must Operate Voltage
- 4.5 VDC
- Coil Current
- 33.3mA
- Must Release Voltage
- -
- Coil Voltage
- 6VDC
- Operating Temperature
- -40°C ~ 70°C
- Contact Form
- DPDT (2 Form C)
- Contact Rating (Current)
- 1A
- Operate Time
- 3ms
- Release Time
- 3ms
