G5RL-K1A-E-DC5
Power Relays, Over 2 Amps
- Manufacturer No:
- G5RL-K1A-E-DC5
- Manufacture:
- Omron Electronics Inc-EMC Div
- Datasheet:
- G5RL-K1A-E-DC5
- Description:
- RELAY GEN PURPOSE SPST 16A 5V
In Stock
1195 pcs On sales
$4.34
Product Parameter
- Coil Type
- Latching, Dual Coil
- Coil Resistance
- 33 Ohms
- Packaging
- Tube
- Contact Material
- -
- Relay Type
- General Purpose
- Switching Voltage
- 250VAC, 24VDC - Max
- Part Status
- Active
- Termination Style
- PC Pin
- Seal Rating
- Sealed - Flux Protection
- Must Operate Voltage
- 3.5 VDC
- Coil Current
- 150mA
- Must Release Voltage
- -
- Coil Voltage
- 5VDC
- Operating Temperature
- -40°C ~ 85°C
- Contact Form
- SPST-NO (1 Form A)
- Contact Rating (Current)
- 16A
- Operate Time
- 15ms
- Release Time
- 15ms
- Series
- G5RL-K
- Mounting Type
- Through Hole
- Features
- -
- Coil Insulation
- -
