G4W-1112P-VD-TV8-HP-DC24
Power Relays, Over 2 Amps
- Manufacturer No:
- G4W-1112P-VD-TV8-HP-DC24
- Manufacture:
- Omron Electronics Inc-EMC Div
- Datasheet:
- G4W-1112P-VD-TV8-HP-DC24
- Description:
- RELAY GEN PURPOSE SPST 15A 24V
In Stock
44 pcs On sales
$9.42
Product Parameter
- Coil Current
- 33.3mA
- Must Release Voltage
- 2.4 VDC
- Coil Voltage
- 24VDC
- Operating Temperature
- -25°C ~ 55°C
- Contact Form
- SPST-NO (1 Form A)
- Contact Rating (Current)
- 15A
- Operate Time
- 20ms
- Release Time
- 5ms
- Series
- G4W
- Mounting Type
- Through Hole
- Features
- -
- Coil Insulation
- -
- Coil Type
- Non Latching
- Coil Resistance
- 720 Ohms
- Packaging
- Bulk
- Contact Material
- Silver Cadmium Oxide (AgCdO)
- Relay Type
- General Purpose
- Switching Voltage
- 250VAC, 125VDC - Max
- Part Status
- Active
- Termination Style
- PC Pin
- Seal Rating
- -
- Must Operate Voltage
- 19.2 VDC
