A6TN-4101
DIP Switches
- Manufacturer No:
- A6TN-4101
- Manufacture:
- Omron Electronics Inc-EMC Div
- Datasheet:
- A6TN-4101
- Description:
- SWITCH SLIDE DIP SPST 25MA 24V
In Stock
1323 pcs On sales
$1.3
Product Parameter
- Length
- 0.476" (12.09mm)
- Voltage Rating
- 24VDC
- Series
- A6TN
- Electrical Life
- 1,000 Cycles
- Circuit
- SPST
- Mechanical Life
- -
- Features
- -
- Contact Material
- -
- Washable
- Yes
- Termination Style
- PC Pin
- Packaging
- Tube
- Height Above Board
- 0.189" (4.80mm)
- Part Status
- Active
- Number of Positions
- 4
- Actuator Type
- Slide (Standard)
- Current Rating (Amps)
- 25mA
- Body Material
- -
- Operating Temperature
- -30°C ~ 85°C
- Mounting Type
- Through Hole
- Actuator Level
- Flush, Recessed
- Pitch
- 0.100" (2.54mm), Full
- Contact Finish
- -
