A6T-2104

DIP Switches

Manufacturer No:
A6T-2104
Manufacture:
Omron Electronics Inc-EMC Div
Datasheet:
A6T-2104
Description:
SWITCH SLIDE DIP SPST 25MA 24V

In Stock

8404 pcs On sales

$1.18

Product Parameter

Features
-
Contact Material
-
Washable
No
Termination Style
PC Pin
Packaging
Tube
Height Above Board
0.165" (4.20mm)
Part Status
Active
Number of Positions
2
Actuator Type
Slide (Standard)
Current Rating (Amps)
25mA
Body Material
-
Operating Temperature
-20°C ~ 70°C
Mounting Type
Through Hole
Actuator Level
Raised
Pitch
0.100" (2.54mm), Full
Contact Finish
-
Length
0.237" (6.02mm)
Voltage Rating
24VDC
Series
A6T
Electrical Life
1,000 Cycles
Circuit
SPST
Mechanical Life
1,000 Cycles
