A6HR-8104-PM
DIP Switches
- Manufacturer No:
- A6HR-8104-PM
- Manufacture:
- Omron Electronics Inc-EMC Div
- Datasheet:
- A6HR-8104-PM
- Description:
- SWITCH PIANO DIP SPST 25MA 24V
In Stock
1582 pcs On sales
$0
Product Parameter
- Part Status
- Active
- Number of Positions
- 8
- Actuator Type
- Piano
- Current Rating (Amps)
- 25mA
- Body Material
- -
- Operating Temperature
- -30°C ~ 85°C
- Mounting Type
- Surface Mount, Right Angle
- Actuator Level
- Raised
- Pitch
- 0.050" (1.27mm), Half
- Contact Finish
- Gold
- Length
- 0.444" (11.28mm)
- Voltage Rating
- 24VDC
- Series
- A6HR
- Electrical Life
- 1,000 Cycles
- Circuit
- SPST
- Mechanical Life
- -
- Features
- -
- Contact Material
- -
- Washable
- No
- Termination Style
- Gull Wing
- Packaging
- Digi-Reel®
- Height Above Board
- 0.165" (4.20mm)
