A6H-8102-PM
DIP Switches
- Manufacturer No:
- A6H-8102-PM
- Manufacture:
- Omron Electronics Inc-EMC Div
- Datasheet:
- A6H-8102-PM
- Description:
- DIP SWITCH
In Stock
2136 pcs On sales
$0
Product Parameter
- Washable
- Yes
- Termination Style
- Gull Wing
- Packaging
- Digi-Reel®
- Height Above Board
- 0.061" (1.55mm)
- Part Status
- Active
- Number of Positions
- 8
- Actuator Type
- Slide (Standard)
- Current Rating (Amps)
- 25mA
- Body Material
- -
- Operating Temperature
- -20°C ~ 70°C
- Mounting Type
- Surface Mount
- Actuator Level
- Flush, Recessed
- Pitch
- 0.050" (1.27mm), Half
- Contact Finish
- -
- Length
- 0.448" (11.39mm)
- Voltage Rating
- 24VDC
- Series
- A6H
- Electrical Life
- 1,000 Cycles
- Circuit
- SPST
- Mechanical Life
- 1,000 Cycles
- Features
- Tape Seal
- Contact Material
- -
