A6FR-4101
DIP Switches
- Manufacturer No:
- A6FR-4101
- Manufacture:
- Omron Electronics Inc-EMC Div
- Datasheet:
- A6FR-4101
- Description:
- SWITCH 4POS PIANO SHORT
In Stock
187 pcs On sales
$1.18
Product Parameter
- Part Status
- Active
- Number of Positions
- 4
- Actuator Type
- Piano
- Current Rating (Amps)
- 25mA
- Body Material
- -
- Operating Temperature
- -20°C ~ 70°C
- Mounting Type
- Through Hole, Right Angle
- Actuator Level
- Flush, Recessed
- Pitch
- 0.100" (2.54mm), Full
- Contact Finish
- -
- Length
- 0.461" (11.71mm)
- Voltage Rating
- 24VDC
- Series
- A6FR
- Electrical Life
- 1,000 Cycles
- Circuit
- SPST
- Mechanical Life
- 1,000 Cycles
- Features
- -
- Contact Material
- -
- Washable
- No
- Termination Style
- PC Pin
- Packaging
- Tube
- Height Above Board
- 0.402" (10.20mm)
