MPX5500DP
Pressure Sensors, Transducers
- Manufacturer No:
- MPX5500DP
- Manufacture:
- NXP USA Inc.
- Package:
- 6-SIP Module
- Datasheet:
- MPX5500DP
- Description:
- IC SENSOR PRESS GAUGE 75PSI RANG
In Stock
182 pcs On sales
$12.84
Product Parameter
- Applications
- Board Mount
- Pressure Type
- Differential
- Package / Case
- 6-SIP Module
- Maximum Pressure
- 406.11PSI (2800kPa)
- Output
- 0.2 V ~ 4.7 V
- Voltage - Supply
- 4.75V ~ 5.25V
- Series
- MPX5500
- Termination Style
- PC Pin
- Accuracy
- ±2.5%
- Operating Pressure
- 72.52PSI (500kPa)
- Features
- Temperature Compensated
- Operating Temperature
- -40°C ~ 125°C
- Port Size
- Male - 0.19" (4.93mm) Tube, Dual
- Supplier Device Package
- -
- Port Style
- Barbed
- Output Type
- Analog Voltage
- Part Status
- Active
