IL 3185-3E
Digital Isolators
- Manufacturer No:
- IL 3185-3E
- Manufacture:
- NVE Corp/Isolation Products
- Package:
- 16-SOIC (0.154", 3.90mm Width)
- Datasheet:
- IL 3185-3E
- Description:
- DGTL ISO RS422/RS485 16SOIC
In Stock
1622 pcs On sales
$5.62
Product Parameter
- Series
- IsoLoop®
- Operating Temperature
- -40°C ~ 85°C
- Data Rate
- 5Mbps
- Inputs - Side 1/Side 2
- 1/1
- Packaging
- Tube
- Rise / Fall Time (Typ)
- 12ns, 12ns
- Technology
- GMR (Giant Magnetoresistive)
- Supplier Device Package
- 16-SOIC
- Part Status
- Active
- Pulse Width Distortion (Max)
- -
- Channel Type
- Unidirectional
- Propagation Delay tpLH / tpHL (Max)
- -
- Mounting Type
- Surface Mount
- Common Mode Transient Immunity (Min)
- 15kV/µs
- Isolated Power
- No
- Package / Case
- 16-SOIC (0.154", 3.90mm Width)
- Voltage - Supply
- 3V ~ 5.5V, 4.5V ~ 5.5V
- Number of Channels
- 2
- Type
- RS422, RS485
- Voltage - Isolation
- 2500Vrms
