174-E15-212-001

D-Sub Connectors

Manufacturer No:: 174-E15-212-001
Manufacture:: NorComp Inc.
Datasheet:: 174-E15-212-001
Description:: CONN D-SUB RCPT 15POS R/A SOLDER

In Stock

57 pcs On sales

$4.67

Product Parameter

Wire Gauge: -

Connector Style: D-Sub

Part Status: Obsolete

Contact Material: -

Termination: Solder

Ingress Protection: -

Contact Form: Machined

Dielectric Material: Polybutylene Terephthalate (PBT)

Contact Type: Signal

Number of Positions: 15

Mounting Type: Panel Mount, Through Hole, Right Angle

Current Rating (Amps): 5A

Connector Type: Receptacle, Female Sockets

Operating Temperature: -50°C ~ 100°C

Contact Finish: Gold

Shell Material, Finish: Steel, Tin Plated

Color: White

Flange Feature: Housing/Shell (Unthreaded)

Contact Finish Thickness: Flash

Series: 174-E

Number of Rows: 2

Material Flammability Rating: UL94 V-0

Features: -

Voltage Rating: -

Shell Size, Connector Layout: 2 (DA, A)

Packaging: -

Backset Spacing: 0.370" (9.40mm)
