GS0090-17M001
Stepper Motors
- Manufacturer No:
- GS0090-17M001
- Manufacture:
- NMB Technologies Corporation
- Datasheet:
- GS0090-17M001
- Description:
- HYBRID 17 STEP MOTOR 1:9 GEARBOX
In Stock
0 pcs On sales
$143.04
Product Parameter
- Accuracy
- -
- Termination Style
- Wire Leads
- Features
- Flatted Shaft
- Steps per Revolution
- 1800
- Approvals
- -
- Current Rating (Amps)
- 850mA
- Coil Type
- Unipolar
- Mounting Hole Spacing
- 1.220" (31.00mm)
- Step Angle
- 0.2°
- Operating Temperature
- -10°C ~ 50°C
- Part Status
- Active
- Length - Shaft and Bearing
- 0.787" (20.00mm)
- Rotor Inertia
- -
- Torque - Holding (oz-in / mNm)
- 70.82 / 500
- Coil Resistance
- 4.2 Ohms
- NEMA Frame Size
- 17
- Voltage - Rated
- 24VDC
- Type
- Hybrid Gear Motor
- Diameter - Shaft
- 0.197" (5.00mm)
- Series
- GS
- Size / Dimension
- Square - 1.654" x 1.654" (42.00mm x 42.00mm)
