FBA08A24M1A

DC Brushless Fans (BLDC)

Manufacturer No:: FBA08A24M1A
Manufacture:: NMB Technologies Corporation
Datasheet:: FBA08A24M1A
Description:: FAN AXIAL 80X25.5MM 24VDC WIRE

In Stock

0 pcs On sales

Product Parameter

Bearing Type: Hydro-wave (HWB)

RPM: 2450 RPM

Power (Watts): 1.70W

Noise: 28.0 dB

Voltage Range: 14 ~ 27.6VDC

Width: 25.50mm

Static Pressure: 0.099 in H2O (24.6 Pa)

Series: FBA

Voltage - Rated: 24VDC

Weight: 0.22 lb (99.79 g)

Lifetime @ Temp.: 50000 Hrs @ 40°C

Air Flow: 32.1 CFM (0.899m³/min)

Material - Blade: -

Fan Type: Tubeaxial

Material - Frame: -

Features: -

Size / Dimension: Square - 80mm L x 80mm H

Approvals: CSA, UL

Ingress Protection: -

Part Status: Obsolete

Current Rating (Amps): 0.071A

Termination: 2 Wire Leads

Operating Temperature: 14 ~ 158°F (-10 ~ 70°C)
