BM6015-04W-B50-L00
DC Brushless Fans (BLDC)
- Manufacturer No:
- BM6015-04W-B50-L00
- Manufacture:
- NMB Technologies Corporation
- Datasheet:
- BM6015-04W-B50-L00
- Description:
- FAN BLOWER 60X15MM 12VDC WIRE
In Stock
0 pcs On sales
$7.94
Product Parameter
- Termination
- 2 Wire Leads
- Operating Temperature
- 14 ~ 158°F (-10 ~ 70°C)
- Bearing Type
- Ball
- RPM
- 5600 RPM
- Power (Watts)
- 2.64W
- Noise
- 42.0 dB
- Voltage Range
- 9 ~ 12.6VDC
- Width
- 15.00mm
- Static Pressure
- 0.678 in H2O (168.9 Pa)
- Series
- BM
- Voltage - Rated
- 12VDC
- Weight
- 0.066 lb (29.94 g)
- Lifetime @ Temp.
- 50000 Hrs @ 25°C
- Air Flow
- 4.2 CFM (0.118m³/min)
- Material - Blade
- Plastic
- Fan Type
- Blower
- Material - Frame
- Plastic
- Features
- -
- Size / Dimension
- Square/Rounded - 60mm L x 60mm H
- Approvals
- CSA
- Ingress Protection
- -
- Part Status
- Active
- Current Rating (Amps)
- 0.220A
