23KM-K762-99V
Stepper Motors
- Manufacturer No:
- 23KM-K762-99V
- Manufacture:
- NMB Technologies Corporation
- Datasheet:
- 23KM-K762-99V
- Description:
- STEP MOTOR HYBRID DUAL SHAFT 24V
In Stock
8 pcs On sales
$82.35
Product Parameter
- Accuracy
- ±5%
- Termination Style
- Wire Leads with Connector
- Features
- Flatted Shaft
- Steps per Revolution
- 200
- Approvals
- -
- Current Rating (Amps)
- 1A
- Coil Type
- Unipolar
- Mounting Hole Spacing
- 1.856" (47.14mm)
- Step Angle
- 1.8°
- Operating Temperature
- -10°C ~ 50°C
- Part Status
- Active
- Length - Shaft and Bearing
- 0.984" (25.00mm)
- Rotor Inertia
- 360gcm²
- Torque - Holding (oz-in / mNm)
- 198.28 / 1400
- Coil Resistance
- 8.6 Ohms
- NEMA Frame Size
- 23
- Type
- Hybrid, Dual Shaft
- Voltage - Rated
- 24VDC
- Series
- 23KM
- Diameter - Shaft
- 0.250" (6.35mm)
- Weight
- 2.3 lbs (1 kg)
- Size / Dimension
- Square - 2.220" x 2.220" (56.40mm x 56.40mm)
