UB215KKW016CF-1JB
Pushbutton Switches
- Manufacturer No:
- UB215KKW016CF-1JB
- Manufacture:
- NKK Switches
- Datasheet:
- UB215KKW016CF-1JB
- Description:
- SWITCH PUSHBUTTON SPDT 5A 125V
In Stock
296 pcs On sales
$14.5
Product Parameter
- Actuator Type
- Square, Button
- Panel Cutout Dimensions
- Square - 17.40mm²
- Mounting Type
- Panel Mount, Snap-In
- Illumination Type, Color
- LED, Red/Green
- Electrical Life
- 10,000 Cycles
- Illumination Voltage (Nominal)
- 2.1, 3.5 VDC
- Mechanical Life
- 1,000,000 Cycles
- Switch Function
- On-Mom
- Termination Style
- Solder Lug
- Type
- Standard, Illuminated
- Ingress Protection
- -
- Series
- UB2
- Voltage Rating - AC
- 125V
- Circuit
- SPDT
- Voltage Rating - DC
- 30V
- Features
- Epoxy Sealed Terminals
- Color - Actuator/Cap
- Clear (White Filter/Diffuser)
- Packaging
- Tray
- Current Rating (Amps)
- 5A (AC/DC)
- Part Status
- Active
- Operating Temperature
- -25°C ~ 50°C
