SK13DAW01
Keylock Switches
- Manufacturer No:
- SK13DAW01
- Manufacture:
- NKK Switches
- Datasheet:
- SK13DAW01
- Description:
- SWITCH KEYLOCK 3POS SPDT 3A 125V
In Stock
702 pcs On sales
$13.76
Product Parameter
- Circuit
- SPDT
- Termination Style
- Solder Lug
- Features
- Epoxy Sealed Terminals
- Depth Behind Flange
- 27.00mm
- Part Status
- Active
- Number of Positions
- 3
- Actuator Type
- Flat Key
- Voltage Rating - AC
- 125V
- Mounting Type
- Panel Mount
- Current Rating (Amps)
- 3A (AC)
- Angle of Throw
- 45°
- Operating Temperature
- -25°C ~ 70°C
- Contact Finish
- -
- Key Removable Positions
- All
- Contact Timing
- Non-Shorting (BBM)
- Panel Cutout Dimensions
- Circular - 12.00mm Dia
- Electrical Life
- 10,000 Cycles
- Mechanical Life
- 30,000 Cycles
- Switch Function
- On-Off-On
- Series
- SK
- Contact Material
- Silver (Ag)
