UVP1H2R2MDD1TD
Aluminum Electrolytic Capacitors
- Manufacturer No:
- UVP1H2R2MDD1TD
- Manufacture:
- Nichicon
- Package:
- Radial, Can
- Datasheet:
- UVP1H2R2MDD1TD
- Description:
- CAP ALUM 2.2UF 20% 50V RADIAL
In Stock
3189 pcs On sales
$0.31
Product Parameter
- Polarization
- Bi-Polar
- Mounting Type
- Through Hole
- Package / Case
- Radial, Can
- Voltage - Rated
- 50V
- Series
- UVP
- Lifetime @ Temp.
- 2000 Hrs @ 85°C
- Ratings
- -
- Size / Dimension
- 0.197" Dia (5.00mm)
- Packaging
- Cut Tape (CT)
- Height - Seated (Max)
- 0.492" (12.50mm)
- Tolerance
- ±20%
- Operating Temperature
- -40°C ~ 85°C
- Capacitance
- 2.2µF
- Surface Mount Land Size
- -
- Part Status
- Active
- Ripple Current @ Low Frequency
- 25mA @ 120Hz
- Applications
- General Purpose
- Ripple Current @ High Frequency
- 50mA @ 10kHz
- Lead Spacing
- 0.098" (2.50mm)
- ESR (Equivalent Series Resistance)
- -
