UMV1HR47MFD1TP
Aluminum Electrolytic Capacitors
- Manufacturer No:
- UMV1HR47MFD1TP
- Manufacture:
- Nichicon
- Package:
- Radial, Can
- Datasheet:
- UMV1HR47MFD1TP
- Description:
- CAP ALUM 0.47UF 20% 50V RADIAL
In Stock
2588 pcs On sales
$0.47
Product Parameter
- Package / Case
- Radial, Can
- Voltage - Rated
- 50V
- Series
- UMV
- Lifetime @ Temp.
- 5000 Hrs @ 105°C
- Ratings
- -
- Size / Dimension
- 0.157" Dia (4.00mm)
- Packaging
- Cut Tape (CT)
- Height - Seated (Max)
- 0.236" (6.00mm)
- Tolerance
- ±20%
- Operating Temperature
- -40°C ~ 105°C
- Capacitance
- 0.47µF
- Surface Mount Land Size
- -
- Part Status
- Not For New Designs
- Ripple Current @ Low Frequency
- 3.8mA @ 120Hz
- Applications
- General Purpose
- Ripple Current @ High Frequency
- 5.7mA @ 10kHz
- Lead Spacing
- 0.059" (1.50mm)
- ESR (Equivalent Series Resistance)
- -
- Polarization
- Polar
- Mounting Type
- Through Hole
