RS80J681MCN1
Aluminum - Polymer Capacitors
- Manufacturer No:
- RS80J681MCN1
- Manufacture:
- Nichicon
- Package:
- Radial, Can
- Datasheet:
- RS80J681MCN1
- Description:
- CAP ALUM POLY 680UF 20% 7.2V T/H
In Stock
5449 pcs On sales
$0.76
Product Parameter
- Mounting Type
- Through Hole
- Package / Case
- Radial, Can
- Voltage - Rated
- 7.2V
- Type
- Polymer
- Lifetime @ Temp.
- 2000 Hrs @ 105°C
- Series
- FPCAP, RS8
- Size / Dimension
- 0.248" Dia (6.30mm)
- Ratings
- -
- Height - Seated (Max)
- 0.354" (9.00mm)
- Packaging
- Bulk
- Operating Temperature
- -55°C ~ 105°C
- Tolerance
- ±20%
- Surface Mount Land Size
- -
- Capacitance
- 680µF
- Ripple Current @ Low Frequency
- 470mA @ 120Hz
- Part Status
- Active
- Ripple Current @ High Frequency
- 4.7A @ 100kHz
- Applications
- General Purpose
- ESR (Equivalent Series Resistance)
- 8mOhm
- Lead Spacing
- 0.098" (2.50mm)
