RPS1A560MCN1GS
Aluminum - Polymer Capacitors
- Manufacturer No:
- RPS1A560MCN1GS
- Manufacture:
- Nichicon
- Package:
- Radial, Can - SMD
- Datasheet:
- RPS1A560MCN1GS
- Description:
- CAP ALUM POLY 56UF 20% 10V SMD
In Stock
2860 pcs On sales
$0
Product Parameter
- Ratings
- -
- Height - Seated (Max)
- 0.224" (5.70mm)
- Packaging
- Digi-Reel®
- Operating Temperature
- -55°C ~ 105°C
- Tolerance
- ±20%
- Surface Mount Land Size
- 0.256" L x 0.256" W (6.50mm x 6.50mm)
- Capacitance
- 56µF
- Ripple Current @ Low Frequency
- 210mA @ 120Hz
- Part Status
- Active
- Ripple Current @ High Frequency
- 2.1A @ 100kHz
- Applications
- General Purpose
- ESR (Equivalent Series Resistance)
- 40mOhm
- Lead Spacing
- -
- Mounting Type
- Surface Mount
- Package / Case
- Radial, Can - SMD
- Voltage - Rated
- 10V
- Type
- Polymer
- Lifetime @ Temp.
- 2000 Hrs @ 105°C
- Series
- FPCAP, RPS
- Size / Dimension
- 0.248" Dia (6.30mm)
