PCJ0J391MCL1GS
Aluminum - Polymer Capacitors
- Manufacturer No:
- PCJ0J391MCL1GS
- Manufacture:
- Nichicon
- Package:
- Radial, Can - SMD
- Datasheet:
- PCJ0J391MCL1GS
- Description:
- CAP ALUM POLY 390UF 20% 6.3V SMD
In Stock
6134 pcs On sales
$0
Product Parameter
- Part Status
- Active
- ESR (Equivalent Series Resistance)
- 14mOhm
- Applications
- General Purpose
- Lead Spacing
- -
- Mounting Type
- Surface Mount
- Package / Case
- Radial, Can - SMD
- Voltage - Rated
- 6.3V
- Type
- Polymer
- Lifetime @ Temp.
- 2000 Hrs @ 105°C
- Series
- PCJ
- Size / Dimension
- 0.315" Dia (8.00mm)
- Ratings
- -
- Height - Seated (Max)
- 0.276" (7.00mm)
- Packaging
- Digi-Reel®
- Operating Temperature
- -55°C ~ 105°C
- Tolerance
- ±20%
- Surface Mount Land Size
- 0.327" L x 0.327" W (8.30mm x 8.30mm)
- Capacitance
- 390µF
- Ripple Current @ High Frequency
- 3.95A @ 100kHz
