LGU2D221MELY

Aluminum Electrolytic Capacitors

Manufacturer No:: LGU2D221MELY
Manufacture:: Nichicon
Package:: Radial, Can - Snap-In
Datasheet:: LGU2D221MELY
Description:: CAP ALUM 220UF 20% 200V SNAP

In Stock

10233 pcs On sales

$2.67

Product Parameter

Capacitance: 220µF

Surface Mount Land Size: -

Part Status: Active

Ripple Current @ Low Frequency: 1A @ 120Hz

Applications: General Purpose

Ripple Current @ High Frequency: 1.5A @ 50kHz

Lead Spacing: 0.394" (10.00mm)

ESR (Equivalent Series Resistance): -

Polarization: Polar

Mounting Type: Through Hole

Package / Case: Radial, Can - Snap-In

Voltage - Rated: 200V

Series: LGU

Lifetime @ Temp.: 3000 Hrs @ 105°C

Ratings: -

Size / Dimension: 0.787" Dia (20.00mm)

Packaging: Bulk

Height - Seated (Max): 0.984" (25.00mm)

Tolerance: ±20%

Operating Temperature: -40°C ~ 105°C
