TZ03T110E169B00
Trimmers, Variable Capacitors
- Manufacturer No:
- TZ03T110E169B00
- Manufacture:
- Murata Electronics North America
- Datasheet:
- TZ03T110E169B00
- Description:
- CAP TRIMMER 3-11PF 100V TH
In Stock
0 pcs On sales
$0
Product Parameter
- Features
- General Purpose
- Q @ Freq
- 500 @ 1MHz
- Packaging
- Bulk
- Part Status
- Obsolete
- Mounting Type
- Through Hole
- Adjustment Type
- Bottom
- Voltage - Rated
- 100V
- Size / Dimension
- 0.236" Dia (6.00mm)
- Capacitance Range
- 3 ~ 11pF
- Dielectric Material
- Ceramic
- Height - Seated (Max)
- 0.209" (5.30mm)
- Series
- TZ03
- Operating Temperature
- -25°C ~ 85°C
