LQH5BPN150MT0L
Fixed Inductors
- Manufacturer No:
- LQH5BPN150MT0L
- Manufacture:
- Murata Electronics
- Package:
- Nonstandard
- Datasheet:
- LQH5BPN150MT0L
- Description:
- FIXED IND 15UH 1.2A 187 MOHM SMD
In Stock
2344 pcs On sales
$0
Product Parameter
- Package / Case
- Nonstandard
- Material - Core
- Ferrite
- Type
- Wirewound
- Size / Dimension
- 0.197" L x 0.197" W (5.00mm x 5.00mm)
- Series
- LQH5
- DC Resistance (DCR)
- 224.4mOhm Max
- Ratings
- -
- Current - Saturation
- 1.6A
- Q @ Freq
- -
- Current Rating (Amps)
- 1.2A
- Packaging
- Digi-Reel®
- Height - Seated (Max)
- 0.087" (2.20mm)
- Shielding
- Shielded
- Operating Temperature
- -40°C ~ 85°C
- Tolerance
- ±20%
- Supplier Device Package
- -
- Inductance
- 15µH
- Frequency - Self Resonant
- 18MHz
- Part Status
- Active
- Inductance Frequency - Test
- 100kHz
- Mounting Type
- Surface Mount
