0482580002

USB, DVI, HDMI Connectors

Manufacturer No:: 0482580002
Manufacture:: Molex
Datasheet:: 0482580002
Description:: CONN RCP USB2.0 TYPEA 4POS TH RA

In Stock

11900 pcs On sales

$1.14

Product Parameter

Gender: Receptacle

Number of Ports: 1

Series: 48258

Voltage - Rated: 250VAC

Features: Board Lock, Solder Retention

Insulation Color: Black

Packaging: Cut Tape (CT)

Mounting Feature: Horizontal, Mid Mount, Reverse

Shielding: Shielded

Ingress Protection: -

Part Status: Active

Number of Contacts: 4

Termination: Solder

Current Rating (Amps): 1.5A

Mating Cycles: -

Operating Temperature: -25°C ~ 85°C

Mounting Type: Board Edge, Cutout; Through Hole, Right Angle

Shell/Shielding Material: Brass

Connector Type: USB - A

Material Flammability Rating: UL94 V-0

Contact Finish: Gold

Specifications: USB 2.0
