2352-3-01-50-00-00-07-0
Terminals - PC Pin, Single Post Connectors
- Manufacturer No:
- 2352-3-01-50-00-00-07-0
- Manufacture:
- Mill-Max Manufacturing Corp.
- Datasheet:
- 2352-3-01-50-00-00-07-0
- Description:
- CONN PC PIN CIRC .094DIA TINLEAD
In Stock
0 pcs On sales
$0.48
Product Parameter
- Termination
- Swage
- Material - Insulation
- -
- Mounting Type
- Through Hole
- Mounting Hole Diameter
- 0.067" (1.70mm)
- Terminal Type
- PC Pin
- Pin Size - Above Flange
- 0.094" (2.39mm) Dia
- Contact Finish
- Tin-Lead
- Pin Size - Below Flange
- -
- Terminal Style
- Single End, Slotted
- Contact Finish Thickness
- 300.0µin (7.62µm)
- Board Thickness
- 0.094" (2.39mm)
- Flange Diameter
- 0.094" (2.39mm)
- Contact Material
- Brass Alloy
- Series
- 2352
- Insulation Color
- -
- Packaging
- Bulk
- Length - Overall
- 0.281" (7.14mm)
- Insulation
- Non-Insulated
- Length - Above Flange
- 0.156" (3.96mm)
- Part Status
- Active
- Length - Below Flange
- 0.125" (3.18mm)
