G9232X24B-FSR
DC Brushless Fans (BLDC)
- Manufacturer No:
- G9232X24B-FSR
- Manufacture:
- Mechatronics Fan Group
- Datasheet:
- G9232X24B-FSR
- Description:
- FAN AXIAL 92X32MM 24VDC
In Stock
0 pcs On sales
$9.94
Product Parameter
- RPM
- 4000 RPM
- Voltage Range
- -
- Noise
- 44.0 dB(A)
- Static Pressure
- 0.330 in H2O (82.2 Pa)
- Width
- 32.00mm
- Voltage - Rated
- 24VDC
- Series
- G9232
- Material - Blade
- Polybutylene Terephthalate (PBT)
- Weight
- 0.335 lb (151.95 g)
- Material - Frame
- Polybutylene Terephthalate (PBT)
- Air Flow
- 68.0 CFM (1.90m³/min)
- Size / Dimension
- Square - 92mm L x 92mm H
- Fan Type
- Tubeaxial
- Ingress Protection
- -
- Features
- Thermal Overload Protector (TOP)
- Current Rating (Amps)
- 0.680A
- Approvals
- CE, cUL, TUV, UL
- Operating Temperature
- -
- Part Status
- Active
- Termination
- 2 Wire Leads
- Bearing Type
- Ball
