G1238M24B-FSR
DC Brushless Fans (BLDC)
- Manufacturer No:
- G1238M24B-FSR
- Manufacture:
- Mechatronics Fan Group
- Datasheet:
- G1238M24B-FSR
- Description:
- FAN AXIAL 120X38MM 24VDC
In Stock
19 pcs On sales
$14.94
Product Parameter
- Features
- Thermal Overload Protector (TOP)
- Ingress Protection
- -
- Approvals
- CE, cUL, TUV, UL
- Current Rating (Amps)
- 0.330A
- Part Status
- Active
- Operating Temperature
- -
- Termination
- 2 Wire Leads
- Bearing Type
- Ball
- RPM
- 2800 RPM
- Voltage Range
- -
- Noise
- 43.0 dB(A)
- Static Pressure
- 0.320 in H2O (79.7 Pa)
- Width
- 38.00mm
- Voltage - Rated
- 24VDC
- Series
- G1238
- Lifetime @ Temp.
- -
- Weight
- 0.74 lb (335.66 g)
- Material - Blade
- Polybutylene Terephthalate (PBT)
- Air Flow
- 125.0 CFM (3.50m³/min)
- Material - Frame
- Polybutylene Terephthalate (PBT)
- Fan Type
- Tubeaxial
- Size / Dimension
- Square - 119mm L x 119mm H
