PWM-60-12
LED Drivers
- Manufacturer No:
- PWM-60-12
- Manufacture:
- MEAN WELL USA Inc.
- Datasheet:
- PWM-60-12
- Description:
- LED DRIVER CV AC/DC 12V 5A
In Stock
169 pcs On sales
$29.57
Product Parameter
- Mounting Type
- Chassis Mount
- Power (Watts)
- 60W
- Size / Dimension
- 5.91" L x 2.09" W x 1.38" H (150.0mm x 53.0mm x 35.0mm)
- Type
- Constant Voltage
- Voltage - Output
- 12V
- Series
- PWM-60 (60W)
- Number of Outputs
- 1
- Dimming
- Analog, PWM
- Termination Style
- Wire Leads
- Ratings
- IP67
- Voltage - Isolation
- 3.75kV
- Features
- OCP, OTP, OVP, SCP
- Operating Temperature
- -40°C ~ 85°C
- Topology
- AC DC Converter
- Voltage - Input (Max)
- 305VAC
- Approvals
- CB, CCC, CE, cURus, ENEC
- Voltage - Input (Min)
- 90VAC
- Efficiency
- 86%
- Current - Output (Max)
- 5A
- Part Status
- Active
