GSC25B-500
LED Drivers
- Manufacturer No:
- GSC25B-500
- Manufacture:
- MEAN WELL USA Inc.
- Datasheet:
- GSC25B-500
- Description:
- LED DRVR CC AC/DC 26-52V 500MA
In Stock
120 pcs On sales
$17.5
Product Parameter
- Features
- SCP
- Operating Temperature
- -30°C ~ 50°C
- Topology
- AC DC Converter
- Voltage - Input (Max)
- 277VAC
- Approvals
- CB, CCC, CE, ENEC, KEMA-KEUR
- Voltage - Input (Min)
- 90VAC
- Efficiency
- 89.5%
- Current - Output (Max)
- 500mA
- Part Status
- Active
- Mounting Type
- Chassis Mount
- Power (Watts)
- 26W
- Size / Dimension
- 3.11" L x 2.13" W x 1.30" H (79.0mm x 54.0mm x 33.0mm)
- Type
- Constant Current
- Voltage - Output
- 26 ~ 52V
- Series
- GSC25B (25W)
- Number of Outputs
- 1
- Dimming
- -
- Termination Style
- Barrel Plug, 2.1mm I.D. x 5.5mm O.D. x 11mm
- Ratings
- IP40
- Voltage - Isolation
- 3.75kV
