L1C1-GRN1000000000
LED Lighting - Color
- Manufacturer No:
- L1C1-GRN1000000000
- Manufacture:
- Lumileds
- Package:
- 0707 (1919 Metric)
- Datasheet:
- L1C1-GRN1000000000
- Description:
- LED LUXEON C GREEN 530NM
In Stock
1587 pcs On sales
$2.45
Product Parameter
- Packaging
- Cut Tape (CT)
- Lumens/Watt @ Current - Test
- 108 lm/W
- Wavelength
- 530nm (520nm ~ 540nm)
- Voltage - Forward (Vf) (Typ)
- 3.05V
- Part Status
- Active
- Thermal Resistance of Package
- 3.5°C/W
- Current - Max
- 1.05A
- Flux @ Current/Temperature - Test
- 115lm (Typ)
- Mounting Type
- Surface Mount
- Viewing Angle
- 170°
- Current - Test
- 350mA
- Package / Case
- 0707 (1919 Metric)
- Size / Dimension
- 0.079" L x 0.079" W (2.00mm x 2.00mm)
- Temperature - Test
- 85°C
- Color
- Green
- Height - Seated (Max)
- 0.059" (1.50mm)
- Series
- LUXEON C
- Supplier Device Package
- SMD
