TRF250-180-2
PTC Resettable Fuses
- Manufacturer No:
- TRF250-180-2
- Manufacture:
- Littelfuse Inc.
- Package:
- Radial, Disc
- Datasheet:
- TRF250-180-2
- Description:
- PTC RESET FUSE 100V 180MA RADIAL
In Stock
1889 pcs On sales
$0.84
Product Parameter
- Voltage - Max
- 100V (250V Int)
- Package / Case
- Radial, Disc
- Type
- Polymeric
- Thickness (Max)
- -
- Series
- PolySwitch®, TRF250
- Size / Dimension
- 0.354" Dia x 0.150" T (9.00mm x 3.80mm)
- Ratings
- -
- Current - Trip (It)
- 650mA
- Approvals
- CSA, TUV, UL
- Height - Seated (Max)
- 0.472" (12.00mm)
- Packaging
- Cut Tape (CT)
- Operating Temperature
- -40°C ~ 85°C
- Part Status
- Active
- Current - Hold (Ih) (Max)
- 180mA
- Lead Spacing
- 0.200" (5.08mm)
- Resistance - Initial (Ri) (Min)
- 800 mOhms
- Time to Trip
- 2s
- Resistance - Post Trip (R1) (Max)
- 4 Ohms
- Current - Max
- 10A
- Mounting Type
- Through Hole
