S4006DRP
Thyristors - SCRs
- Manufacturer No:
- S4006DRP
- Manufacture:
- Littelfuse Inc.
- Package:
- TO-252-3, DPak (2 Leads + Tab), SC-63
- Datasheet:
- S4006DRP
- Description:
- SCR NON-SENS 400V 6A TO-252AA
In Stock
42336 pcs On sales
$1.17
Product Parameter
- Voltage - On State (Vtm) (Max)
- 1.6V
- Series
- -
- Current - Gate Trigger (Igt) (Max)
- 15mA
- SCR Type
- Standard Recovery
- Current - On State (It (AV)) (Max)
- 3.8A
- Packaging
- Cut Tape (CT)
- Voltage - Gate Trigger (Vgt) (Max)
- 1.5V
- Part Status
- Active
- Current - On State (It (RMS)) (Max)
- 6A
- Mounting Type
- Surface Mount
- Current - Non Rep. Surge 50, 60Hz (Itsm)
- 83A, 100A
- Package / Case
- TO-252-3, DPak (2 Leads + Tab), SC-63
- Voltage - Off State
- 400V
- Operating Temperature
- -40°C ~ 125°C
- Supplier Device Package
- TO-252, (D-Pak)
- Current - Hold (Ih) (Max)
- 30mA
- Current - Off State (Max)
- 10µA
