RUEF135
PTC Resettable Fuses
- Manufacturer No:
- RUEF135
- Manufacture:
- Littelfuse Inc.
- Package:
- Radial, Disc
- Datasheet:
- RUEF135
- Description:
- PTC RESET FUSE 30V 1.35A RADIAL
In Stock
7925 pcs On sales
$0.43
Product Parameter
- Ratings
- -
- Current - Trip (It)
- 2.7A
- Approvals
- CQC, CSA, TUV, UL
- Height - Seated (Max)
- 0.532" (13.50mm)
- Packaging
- Bulk
- Operating Temperature
- -40°C ~ 85°C
- Part Status
- Active
- Current - Hold (Ih) (Max)
- 1.35A
- Lead Spacing
- 0.199" (5.05mm)
- Resistance - Initial (Ri) (Min)
- 40 mOhms
- Time to Trip
- 7.3s
- Resistance - Post Trip (R1) (Max)
- 130 mOhms
- Current - Max
- 100A
- Mounting Type
- Through Hole
- Voltage - Max
- 30V
- Package / Case
- Radial, Disc
- Type
- Polymeric
- Thickness (Max)
- -
- Series
- PolySwitch®, RUEF
- Size / Dimension
- 0.350" L x 0.118" W (8.90mm x 3.00mm)
