MCR12DCNT4G
Thyristors - SCRs
- Manufacturer No:
- MCR12DCNT4G
- Manufacture:
- Littelfuse Inc.
- Package:
- TO-252-3, DPak (2 Leads + Tab), SC-63
- Datasheet:
- MCR12DCNT4G
- Description:
- THYRISTOR SCR 12A 800V DPAK
In Stock
3100 pcs On sales
$0
Product Parameter
- Series
- -
- Voltage - On State (Vtm) (Max)
- 1.9V
- SCR Type
- Standard Recovery
- Current - Gate Trigger (Igt) (Max)
- 20mA
- Packaging
- Digi-Reel®
- Current - On State (It (AV)) (Max)
- 7.8A
- Part Status
- Active
- Voltage - Gate Trigger (Vgt) (Max)
- 1V
- Mounting Type
- Surface Mount
- Current - On State (It (RMS)) (Max)
- 12A
- Package / Case
- TO-252-3, DPak (2 Leads + Tab), SC-63
- Current - Non Rep. Surge 50, 60Hz (Itsm)
- 100A @ 60Hz
- Base Part Number
- MCR12
- Voltage - Off State
- 800V
- Operating Temperature
- -40°C ~ 125°C
- Supplier Device Package
- DPAK
- Current - Hold (Ih) (Max)
- 40mA
- Current - Off State (Max)
- 10µA
