MAC4DHMT4G
Thyristors - TRIACs
- Manufacturer No:
- MAC4DHMT4G
- Manufacture:
- Littelfuse Inc.
- Package:
- TO-252-3, DPak (2 Leads + Tab), SC-63
- Datasheet:
- MAC4DHMT4G
- Description:
- TRIAC SENS GATE 600V 4A DPAK
In Stock
55295 pcs On sales
$0
Product Parameter
- Triac Type
- Logic - Sensitive Gate
- Current - On State (It (RMS)) (Max)
- 4A
- Part Status
- Active
- Current - Non Rep. Surge 50, 60Hz (Itsm)
- 40A @ 60Hz
- Configuration
- Single
- Mounting Type
- Surface Mount
- Package / Case
- TO-252-3, DPak (2 Leads + Tab), SC-63
- Base Part Number
- MAC4
- Voltage - Off State
- 600V
- Operating Temperature
- -40°C ~ 110°C (TJ)
- Supplier Device Package
- DPAK
- Current - Hold (Ih) (Max)
- 15mA
- Series
- -
- Current - Gate Trigger (Igt) (Max)
- 5mA
- Packaging
- Digi-Reel®
- Voltage - Gate Trigger (Vgt) (Max)
- 1.3V
