59045-1-U-00-0
Magnetic, Reed Switches
- Manufacturer No:
- 59045-1-U-00-0
- Manufacture:
- Littelfuse Inc.
- Datasheet:
- 59045-1-U-00-0
- Description:
- SWITCH REED SPST-NO 350MA 140V
In Stock
0 pcs On sales
$0
Product Parameter
- Operate Range
- 25 ~ 30AT
- Power - Rated
- 10W
- Type
- Molded Body
- Release Range
- -
- Series
- 59045
- Current - Carry
- 1.2A (DC)
- Circuit
- SPST-NO
- Length - Overall
- 0.700" (17.78mm)
- Packaging
- Bulk
- Termination Style
- PC Pin
- Capacitance
- 0.3pF
- Height Above Board
- 0.170" (4.33mm)
- Part Status
- Active
- Current - Switching
- 350mA (AC), 500mA (DC)
- Size - Body
- 0.700" L x 0.130" W x 0.170" H (17.78mm x 3.30mm x 4.32mm)
- Operating Temperature
- -40°C ~ 105°C
- Operate Time
- 1ms
- Voltage - Switching AC
- 140V
- Release Time
- 1ms
- Voltage - Switching DC
- 200V
- Mounting Type
- Through Hole
