11113
Terminals - Turret Connectors
- Manufacturer No:
- 11113
- Manufacture:
- Keystone Electronics
- Datasheet:
- 11113
- Description:
- TERM TURRET HOLLOW L=8.33MM TIN
In Stock
1186 pcs On sales
$1.57
Product Parameter
- Staking Side OD
- -
- Contact Material
- Brass
- Series
- -
- Insulation Color
- White
- Insulation
- Insulated
- Length - Overall
- 0.478" (12.14mm)
- Part Status
- Active
- Number of Turrets
- Single
- Termination
- Press-Fit
- Length - Above Board
- 0.328" (8.33mm)
- Mounting Type
- Through Hole
- Length - Below Flange
- 0.150" (3.81mm)
- Terminal Type
- Single End, Fork, Hollow
- Material - Insulation
- Polytetrafluoroethylene (PTFE)
- Contact Finish
- Tin
- Diameter - Turret Head
- -
- Board Thickness
- 0.062" (1.57mm)
- Mounting Hole Diameter
- 0.158" (4.01mm)
- Flange Diameter
- 0.187" (4.75mm)
- Contact Finish Thickness
- -
- Staking Side ID
- -
