Q 0,032768-JTX310-9-20-T3-HMR-LF
Crystals
- Manufacturer No:
- Q 0,032768-JTX310-9-20-T3-HMR-LF
- Manufacture:
- Jauch Quartz
- Package:
- 2-SMD, No Lead
- Datasheet:
- Q 0,032768-JTX310-9-20-T3-HMR-LF
- Description:
- CRYSTAL 32.768KHZ 9PF SMD
In Stock
5945 pcs On sales
$0.63
Product Parameter
- Part Status
- Active
- Mounting Type
- Surface Mount
- Operating Mode
- Fundamental
- Package / Case
- 2-SMD, No Lead
- Load Capacitance
- 9pF
- Size / Dimension
- 0.126" L x 0.059" W (3.20mm x 1.50mm)
- Frequency Stability
- -
- Type
- kHz Crystal (Tuning Fork)
- Frequency Tolerance
- ±20ppm
- Series
- JTX310
- Height - Seated (Max)
- 0.035" (0.90mm)
- Ratings
- AEC-Q200
- Operating Temperature
- -40°C ~ 125°C
- Frequency
- 32.768kHz
- ESR (Equivalent Series Resistance)
- 80 kOhms
- Packaging
- Cut Tape (CT)
