JL05-6A24-28P-R
Circular Connectors
- Manufacturer No:
- JL05-6A24-28P-R
- Manufacture:
- JAE Electronics
- Datasheet:
- JL05-6A24-28P-R
- Description:
- CONN PLUG MALE 24POS SOLDER
In Stock
5 pcs On sales
$87.94
Product Parameter
- Part Status
- Active
- Contact Material
- Copper Alloy
- Termination
- Solder
- Mounting Feature
- -
- Applications
- Industrial, Marine, Telecommunications
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Shell Finish
- Zinc
- Number of Positions
- 24 (23 + PE)
- Cable Opening
- 1.291" (32.80mm)
- Shell Size - Insert
- 24-28
- Mounting Type
- Free Hanging (In-Line)
- Current Rating (Amps)
- 13A
- Color
- Black
- Connector Type
- Plug, Male Pins
- Operating Temperature
- -55°C ~ 125°C
- Series
- JL05
- Fastening Type
- Bayonet Lock
- Contact Finish - Mating
- Silver
- Features
- Coupling Nut, Ground Lug
- Shell Material
- Aluminum Alloy
- Backshell Material, Plating
- -
- Packaging
- Bulk
- Voltage Rating
- -
- Material Flammability Rating
- -
- Shielding
- -
- Insert Material
- Synthetic Resin
- Contact Finish Thickness - Mating
- -
- Orientation
- N (Normal)
- Shell Size, MIL
- -
