FA5S020HP1R3000
FFC, FPC (Flat Flexible) Connectors
- Manufacturer No:
- FA5S020HP1R3000
- Manufacture:
- JAE Electronics
- Datasheet:
- FA5S020HP1R3000
- Description:
- CONN FPC BOTTOM 20POS 0.50MM R/A
In Stock
0 pcs On sales
$2.05
Product Parameter
- Actuator Color
- White
- Current Rating (Amps)
- 0.8A per Contact
- Cable End Type
- Tapered
- Operating Temperature
- -40°C ~ 85°C
- Contact Finish
- Gold
- Connector/Contact Type
- Contacts, Bottom
- Pitch
- 0.020" (0.50mm)
- Flat Flex Type
- FPC
- Contact Finish Thickness
- -
- Series
- FA5
- Voltage Rating
- 50V
- Material Flammability Rating
- UL94 V-0
- Features
- Solder Retention, Zero Insertion Force (ZIF)
- Locking Feature
- Flip Lock
- Packaging
- Tape & Reel (TR)
- Contact Material
- Copper Alloy
- Part Status
- Active
- Actuator Material
- Polyamide (PA), Nylon, Glass Filled
- Termination
- Solder
- FFC, FCB Thickness
- 0.30mm
- Housing Color
- Black
- Height Above Board
- 0.057" (1.45mm)
- Mating Cycles
- 20
- Dielectric Material
- Liquid Crystal Polymer (LCP), Glass Filled
- Mounting Type
- Surface Mount, Right Angle
- Number of Positions
- 20
