IRG4PC50FDPBF
Transistors - IGBTs - Single
- Manufacturer No:
- IRG4PC50FDPBF
- Manufacture:
- Infineon Technologies
- Package:
- TO-247-3
- Datasheet:
- IRG4PC50FDPBF
- Description:
- IGBT 600V 70A 200W TO247AC
In Stock
1849 pcs On sales
$8.79
Product Parameter
- Mounting Type
- Through Hole
- Package / Case
- TO-247-3
- Test Condition
- 480V, 39A, 5Ohm, 15V
- Switching Energy
- 1.5mJ (on), 2.4mJ (off)
- Td (on/off) @ 25°C
- 55ns/240ns
- Series
- -
- Operating Temperature
- -55°C ~ 150°C (TJ)
- IGBT Type
- -
- Supplier Device Package
- TO-247AC
- Packaging
- Tray
- Vce(on) (Max) @ Vge, Ic
- 1.6V @ 15V, 39A
- Input Type
- Standard
- Reverse Recovery Time (trr)
- 50ns
- Gate Charge
- 190nC
- Current - Collector (Ic) (Max)
- 70A
- Part Status
- Not For New Designs
- Current - Collector Pulsed (Icm)
- 280A
- Power - Max
- 200W
- Voltage - Collector Emitter Breakdown (Max)
- 600V
