158LMH250MZEF
Aluminum Electrolytic Capacitors
- Manufacturer No:
- 158LMH250MZEF
- Manufacture:
- Illinois Capacitor
- Package:
- Radial, Can - Snap-In
- Datasheet:
- 158LMH250MZEF
- Description:
- CAP ALUM 1500UF 20% 250V SNAP
In Stock
0 pcs On sales
$4.3
Product Parameter
- Capacitance
- 1500µF
- Surface Mount Land Size
- -
- Part Status
- Active
- Ripple Current @ Low Frequency
- 2.3A @ 120Hz
- Applications
- General Purpose
- Ripple Current @ High Frequency
- 3.381A @ 50kHz
- Lead Spacing
- 0.394" (10.00mm)
- ESR (Equivalent Series Resistance)
- 165.786mOhm @ 120Hz
- Polarization
- Polar
- Mounting Type
- Through Hole
- Package / Case
- Radial, Can - Snap-In
- Voltage - Rated
- 250V
- Series
- LMH
- Lifetime @ Temp.
- 2000 Hrs @ 105°C
- Ratings
- -
- Size / Dimension
- 1.378" Dia (35.00mm)
- Packaging
- Bulk
- Height - Seated (Max)
- 1.654" (42.00mm)
- Tolerance
- ±20%
- Operating Temperature
- -25°C ~ 105°C
