97C08SRT
DIP Switches
- Manufacturer No:
- 97C08SRT
- Manufacture:
- Grayhill, Inc.
- Datasheet:
- 97C08SRT
- Description:
- SWITCH SLIDE DIP SPST 25MA 24V
In Stock
89331 pcs On sales
$0
Product Parameter
- Part Status
- Active
- Number of Positions
- 8
- Actuator Type
- Slide (Standard)
- Current Rating (Amps)
- 25mA
- Body Material
- Polyamide (PA), Nylon
- Operating Temperature
- -40°C ~ 85°C
- Mounting Type
- Surface Mount
- Actuator Level
- Flush, Recessed
- Pitch
- 0.050" (1.27mm), Half
- Contact Finish
- Gold
- Length
- 0.448" (11.39mm)
- Voltage Rating
- 24VDC
- Series
- 97
- Electrical Life
- -
- Circuit
- SPST
- Mechanical Life
- 1,000 Cycles
- Features
- Tape Seal
- Contact Material
- Copper Alloy
- Washable
- Yes
- Termination Style
- Gull Wing
- Packaging
- Digi-Reel®
- Height Above Board
- 0.063" (1.60mm)
