90HBW06PRT
DIP Switches
- Manufacturer No:
- 90HBW06PRT
- Manufacture:
- Grayhill, Inc.
- Datasheet:
- 90HBW06PRT
- Description:
- SWITCH SLIDE DIP SPST 25MA 24V
In Stock
4716 pcs On sales
$0
Product Parameter
- Series
- 90HB
- Electrical Life
- 2,000 Cycles
- Circuit
- SPST
- Mechanical Life
- 2,000 Cycles
- Features
- Tape Seal
- Contact Material
- Copper Alloy
- Washable
- Yes
- Termination Style
- Gull Wing
- Packaging
- Digi-Reel®
- Height Above Board
- 0.190" (4.83mm)
- Part Status
- Active
- Number of Positions
- 6
- Actuator Type
- Slide (Standard)
- Current Rating (Amps)
- 25mA
- Body Material
- Thermoplastic
- Operating Temperature
- -40°C ~ 85°C
- Mounting Type
- Surface Mount
- Actuator Level
- Flush, Recessed
- Pitch
- 0.100" (2.54mm), Full
- Contact Finish
- Gold
- Length
- 0.670" (17.02mm)
- Voltage Rating
- 24VDC
