76PSB04ST
DIP Switches
- Manufacturer No:
- 76PSB04ST
- Manufacture:
- Grayhill, Inc.
- Datasheet:
- 76PSB04ST
- Description:
- SWITCH PIANO DIP SPST 150MA 30V
In Stock
5988 pcs On sales
$1.38
Product Parameter
- Pitch
- 0.100" (2.54mm), Full
- Contact Finish
- Gold
- Length
- 0.480" (12.19mm)
- Voltage Rating
- 30VDC
- Series
- 76
- Electrical Life
- 2,000 Cycles
- Circuit
- SPST
- Mechanical Life
- 2,000 Cycles
- Features
- Tape Seal
- Contact Material
- Copper Alloy
- Washable
- Yes
- Termination Style
- PC Pin
- Packaging
- Tube
- Height Above Board
- 0.301" (7.65mm)
- Part Status
- Active
- Number of Positions
- 4
- Actuator Type
- Piano
- Current Rating (Amps)
- 150mA
- Body Material
- Thermoplastic
- Operating Temperature
- -40°C ~ 85°C
- Mounting Type
- Through Hole, Right Angle
- Actuator Level
- Raised
