44D30-02-1-AJN
Rotary Switches
- Manufacturer No:
- 44D30-02-1-AJN
- Manufacture:
- Grayhill, Inc.
- Datasheet:
- 44D30-02-1-AJN
- Description:
- SWITCH ROTARY 2-12POS 1A 115V
In Stock
66 pcs On sales
$58.24
Product Parameter
- Features
- -
- Contact Material
- Silver Alloy
- Index Stops
- Adjustable
- Termination Style
- Solder Lug
- Part Status
- Active
- Depth Behind Panel
- 34.82mm
- Actuator Type
- Flatted (6.35mm Dia)
- Number of Positions
- 2 ~ 12
- Mounting Type
- Panel Mount
- Voltage Rating - AC
- 115V
- Angle of Throw
- 30°
- Voltage Rating - DC
- 28V
- Contact Finish
- -
- Current Rating (Amps)
- 1A (AC/DC)
- Contact Timing
- Non-Shorting (BBM)
- Panel Cutout Dimensions
- -
- Actuator Length
- 11.10mm
- Number of Poles per Deck
- 1
- Number of Decks
- 2
- Operating Force
- 5.761 ~ 83gfm
- Series
- 44
- Circuit per Deck
- SP12T
