ELSW-F91R3-0LPNM-BR4R6
LED Lighting - Color
- Manufacturer No:
- ELSW-F91R3-0LPNM-BR4R6
- Manufacture:
- Everlight Electronics Co Ltd
- Package:
- 1414 (3535 Metric)
- Datasheet:
- ELSW-F91R3-0LPNM-BR4R6
- Description:
- LED SHWO 3W HI PWR RED SMD
In Stock
0 pcs On sales
$0
Product Parameter
- Current - Test
- 700mA
- Package / Case
- 1414 (3535 Metric)
- Size / Dimension
- 0.138" L x 0.138" W (3.50mm x 3.50mm)
- Temperature - Test
- 25°C
- Color
- Red
- Height - Seated (Max)
- 0.088" (2.23mm)
- Series
- SHWO
- Supplier Device Package
- SMD
- Packaging
- Digi-Reel®
- Lumens/Watt @ Current - Test
- 51 lm/W
- Wavelength
- 623nm (615nm ~ 630nm)
- Voltage - Forward (Vf) (Typ)
- 2.65V
- Part Status
- Discontinued at Digi-Key
- Thermal Resistance of Package
- 8°C/W
- Current - Max
- 750mA
- Flux @ Current/Temperature - Test
- 95lm (90lm ~ 100lm)
- Mounting Type
- Surface Mount
- Viewing Angle
- 120°
